SYSTEM
Effective Freq. Range
74 Hz-20 kHz (-10dB)
Coverage angle / Dispersion
151°x151° (HxV)
Power handling
40 W RMS / 160 W Peak
Sensitivity
90 dB (1W/1m)
Maximum SPL
106 dB continuous / 112 dB peak
Power options (Hi Z Multi-tap)
100V: 32W / 16W / 8W / 4W / 8Ω
70V: 16W / 8W / 4W / 2W / 8Ω
70V: 16W / 8W / 4W / 2W / 8Ω
Recommended amplifier power
80 W RMS
