VEO-SWH44

VEO-SWH44 is a 4x1 HDMI® switcher for high dynamic range (HDR) formats. It is the ideal solution for applications requiring 4K/UHD and HDR sources and displays. VEO-SWH44 includes audio de-embedding features and audio EDID management. The HDMI® selection could be automatic (sense selection) and manual (frontal panel, remote control or serial commands). The controls include ARC mute and LED indications of the selected sources and settings.

• 4x1 Ultra High Definition sources selector compliant with HDMI® standards
• Video formats up to 4Kx2K(4096x2160@60Hz YUV 4:4:4) and all HDMI® video formats
• Supports HDR and 3D contents
• HDCP2.2/1.4 Compliant
• Supports 36 bit Deep Color
• Smart EDID management (Auto/2CH/5.1CH/7.1CH selectable)
• PCM, Dolby TrueHD, DTS-HD Master Audio up to 7.1CH
• Supports Audio Return Channel (ARC)
• Digital and analog audio output
• RS-232 Control
• Supports up to 18Gbps video data rate

Applications

Retail   Leisure   Sports & Wellness   Hospitality
